Need a Ready-to-use Image for left SD/MMC with Pandora OS Linux for the Pandora handheld ?


openbsd98324

Still Fresh
Joined
Jan 7, 2022
Messages
46
Hello

I would need an image : a ready-to-use Image for left SD/MMC with Pandora OS Linux for the Pandora handheld ?

Currently I guess we have 3.2.57 kernel.

I need wifi and desktop, alike the default OS. However, I would need an image *.img.gz to zcat to the SD/MMC so that i can boot from the left SD card reader.

Thank you in advance.
Kind regards


ingoreis

Hardcore Member
Staff member
Joined
Jan 18, 2010
Messages
8,244
Age
41
Location
49.491276,8.423518
Hi..this is little bit old but you should can use

sudo opkg update
sudo opkg upgrade

..to update this Image



Edit:

There exist also a Pandora Multiboot Image with many many Linux Versions for Pandora here:

Last edited:

ingoreis

Hardcore Member
Staff member
Joined
Jan 18, 2010
Messages
8,244
Age
41
Location
49.491276,8.423518
The above link gives a *.imz image.
Any *.imz image is not a classic extension.


Is there just a regular *-img.gz file, so that one can use zcat / dd ? (as usual).
Uhm i think its an Diskdump Zip File and not an Diskdump Gzip File.

Easiest Way is to use this Software under Windows or with Wine to write it to an SD Card:

@that Time it was much more easy to create SD Images for me and i still use today this Software :)

Edit:
Hi,i simply tried it with unzip the .imz File and i got an 16GB .ima file.
.ima should be the Same as .img and you can write it with DiskDump to a SD Card.

Last edited:

PowerGod

Forum Addict!
Joined
Jun 20, 2011
Messages
4,143
@openbsd98324 , maybe I'm not understanding what you want, but if you need an image to be run from the Pandora that's not the right one... I'm not sure what that image contains, but it's like 3 GB, too much for the Pandora internal storage... In the download link I can read QEMU, so if the image contains that emulator too maybe it's meant to run the Pandora OS on a PC with a different CPU... but that's just a guess...

Have you had a look here ?

EDIT:
ok now is more clear, I didn't see that the image link was the one that released @ingoreis

Last edited:

ingoreis

Hardcore Member
Staff member
Joined
Jan 18, 2010
Messages
8,244
Age
41
Location
49.491276,8.423518
In the download link I can read QEMU
It has nothing to do with Qemu..it was @ a Time where i got Access to the OpenPandora Server to upload Qemu Images and i used this to upload a SuperZaxxon OpenPandora SD Card Image too :)

The Image from the Link have the OS Bootable from a SD Card and some extra Software..thats beacause its around 3GB big.
;)

When i do understand him right?....then he want a Pandora OS SD Card to use the OS on an SD Card and no Card Image to reflash the OS :)


levi

Still fresh, damnit!
Joined
Oct 6, 2008
Messages
15,682
Location
Somewhere off the coast of the EU
I assume from the title at least that he's looking for an image to burn to an SD card using whatever OS on a computer to boot from a left SD slot to reimage the NAND, which I think is limited to 256MB or maybe 512MB.

I guess reading the OP now he could want a card he can actually boot from, but he didn't specify so the above is my guess.


HelenF

Very Active Member
Joined
Jun 22, 2013
Messages
602
Location
UK
Right, I'm not sure what the question is. Do you want to reflash the Pandora, or run the regular Pandora OS from the SD card? And why do you "need an image"? The normal boot process doesn't need things to be in any particular sector on the SD card, so normally we just partition the card and copy the files. If the bootloader on the NAND is corrupted so the Pandora can't read filesystem-based bootable cards, there is a recovery card image available.


openbsd98324

Still Fresh
Joined
Jan 7, 2022
Messages
46
"Note: Reflashing the firmware will delete all personal installed data on your Pandora and reverts to factory settings"
it was not asked to reflash with Zaxxon


pandian-mark2-hf_2014-01-02.img.gz is way too old. Furthermore it is debian, and once apt-get gets old, nothing starts to work.

Uhm i think its an Diskdump Zip File and not an Diskdump Gzip File.

Easiest Way is to use this Software under Windows or with Wine to write it to an SD Card:

@that Time it was much more easy to create SD Images for me and i still use today this Software :)

Edit:
Hi,i simply tried it with unzip the .imz File and i got an 16GB .ima file.
.ima should be the Same as .img and you can write it with DiskDump to a SD Card.

Diskdump is for Windows.
We leave the MS Windows world for lamers.

Is there a serious image for Linux, BSD; and the Free Operating System Spirit ?

Like tar, or gzip.


HelenF

Very Active Member
Joined
Jun 22, 2013
Messages
602
Location
UK
You still haven't explained what you want, only a subset of the things you don't want. And like I said, why do you need an image?

Is the question "How to install the latest SuperZaxxon onto SD card, so that you can boot and use it from the SD card without writing to the NAND?" There's some info about that here:
I've had a bad time on the Pandora with EXT2 SD cards getting corrupted beyond the help of fsck. When I did the SD Card SuperZaxxon install, I think I had a FAT partition with boot.txt and the kernel, and EXT4 for the rootfs.

Last edited:

openbsd98324

Still Fresh
Joined
Jan 7, 2022
Messages
46
any news guys - dormant thread...

The only solution was to use Microsoft Windows with imz. I dont know what kind of format from MS and Bill Gates. We don't buy Windows here ;)

Is there an opensource format like tar.gz or img.gz ?

You cannot be serious,... we have gzip, rawrite even for windows,... and it works for over years until now.


Attachments

  • kidding.png
    115.3 KB · Views: 11
Last edited:

HelenF

Very Active Member
Joined
Jun 22, 2013
Messages
602
Location
UK
You still haven't told us clearly what result you're looking for, so we can't help you ;)


TrashyMG

Sarcasm Dispenser
Staff member
Joined
Jan 18, 2010
Messages
11,214
any news guys - dormant thread...

The only solution was to use Microsoft Windows with imz. I dont know what kind of format from MS and Bill Gates. We don't buy Windows here ;)

Is there an opensource format like tar.gz or img.gz ?

You cannot be serious,... we have gzip, rawrite even for windows,... and it works for over years until now.
From my understanding imz is just an img file gzipped... rename the file to .img.gz and run gunzip.

Also Zaxxon1.55 is old, extremely old, it's not even SuperZaxxon which is the present state of the OS. Not even sure how you dug this file up.


HelenF

Very Active Member
Joined
Jun 22, 2013
Messages
602
Location
UK
Not sure if "how to run SuperZaxxon from SD card" is the OP's question or not, but it's on my mind now.

I just tested the basic version of the instructions on the wiki and they do work.

1. Format the card with a single EXT2 partition.
2. Extract the contents of http://openpandora.org/firmware/pandora-rootfs.tar.bz2 onto it.
3. Create boot.txt or autoboot.txt in the root of the filesystem with the following contents:

Code:
setenv bootargs root=/dev/mmcblk0p1 rw rootwait vram=6272K omapfb.vram=0:3000K mmc_core.removable=0
ext2load mmc 0 0x80300000 /boot/uImage-3
bootm 0x80300000

However, IMO, this is an unsatisfactory/unsafe way to run an OS. When I posted before, I thought I'd got the advanced version to work in the past, but it appears I possibly didn't. Going to try it again.


openbsd98324

Still Fresh
Joined
Jan 7, 2022
Messages
46
From my understanding imz is just an img file gzipped... rename the file to .img.gz and run gunzip.

Also Zaxxon1.55 is old, extremely old, it's not even SuperZaxxon which is the present state of the OS. Not even sure how you dug this file up.

It seems to not work... :(

Code:
james@DEVUAN:~$ zcat Zaxxon1.55-31.07.2013.imz > Zaxxon1.55-31.07.2013.img
gzip: Zaxxon1.55-31.07.2013.imz: invalid compressed data--length error


TrashyMG

Sarcasm Dispenser
Staff member
Joined
Jan 18, 2010
Messages
11,214
It seems to not work... :(

Code:
james@DEVUAN:~$ zcat Zaxxon1.55-31.07.2013.imz > Zaxxon1.55-31.07.2013.img
gzip: Zaxxon1.55-31.07.2013.imz: invalid compressed data--length error
Well Zaxxon1.55 is so old not sure I'd trust that image anyway. lot of changes to charging settings, power efficiency and such has been done since then and the latest version. I'd follow HelenF and just install the latest to an SD card.


HelenF

Very Active Member
Joined
Jun 22, 2013
Messages
602
Location
UK
Looks like the OP hasn't even acknowledged any of my comments. If they ask really nicely, I might even be willing to make an image for them once I've figured out the best setup here, but if they're not talking to me I guess that won't happen ;)


HelenF

Very Active Member
Joined
Jun 22, 2013
Messages
602
Location
UK
OK, I think I got it.

Partitioned the card as follows:
4MiB unallocated (for flash alignment)
128MiB EXT2 "SZBOOT"
512MiB linux-swap "SZSWAP"
remainder EXT4 "SZROOT"

Extracted the contents of http://openpandora.org/firmware/pandora-rootfs.tar.bz2 into SZROOT.
Copied SZROOT/boot/uImage-3 to SZBOOT.
Created boot.txt in SZBOOT with the following contents:

Code:
setenv bootargs root=/dev/mmcblk0p3 rw rootwait vram=6272K omapfb.vram=0:3000K mmc_core.removable=0
ext2load mmc 0 0x80300000 /uImage-3
bootm 0x80300000

Edited SZROOT/etc/fstab. Deleted the "ubi1:boot" line. Added the following:

Code:
LABEL=SZBOOT         /boot                ext2       defaults              0  0
LABEL=SZSWAP         swap                 swap       defaults              0  0
